Hero

Lighting for Industry

Passive Cooling

Smooth Cover for Easy Cleaning

Flexible Mounting

Surface mount, Suspend or use the adjustable bracket accessory to ceiling or wall mount at an angle.

Powerful and Efficient

15,0000, 30,000 or 60,000 Lumens.

  Hero’s lensed LEDs are available with three distribution options to match mounting heights and application.

Product Selection

Product Filters

Size
(mm)		 Optic
 Lumen
Output		 Light
Colour		 CRI
(Ra)		 Lm/W UGR
Rating		 Driver
Type		 Body
Colour
Image Part Code
Article Number		 Size
(mm)		 Optic
 Lumen
Output		 Light
Colour		 CRI
(Ra)		 Lm/W
 UGR
Rating		 Driver
Type		 Body
Colour		 Data LDT Polar BIM
Product ImageHERO 1500-840 M-DA
0667473		337 mmMedium15000 lm4000 K≥ 80123,0 lm/W≤ 22DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-840 M-ND
0657473		337 mmMedium15000 lm4000 K≥ 80123,0 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-840 S-DA
0667465		337 mmSpot15150 lm4000 K≥ 80124,2 lm/W≤ 22DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-840 S-ND
0657465		337 mmSpot15150 lm4000 K≥ 80124,2 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-840 SF-DA
0667457		337 mmSuper Flood14200 lm4000 K≥ 80116,4 lm/W≤ 25DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-840 SF-ND
0657457		337 mmSuper Flood14200 lm4000 K≥ 80116,4 lm/W≤ 25On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-865 M-DA
0667474		337 mmMedium15000 lm6500 K≥ 80123,0 lm/W≤ 22DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-865 M-ND
0657474		337 mmMedium15000 lm6500 K≥ 80123,0 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-865 S-DA
0667466		337 mmSpot15150 lm6500 K≥ 80124,2 lm/W≤ 22DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-865 S-ND
0657466		337 mmSpot15150 lm6500 K≥ 80124,2 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-865 SF-DA
0667458		337 mmSuper Flood14200 lm6500 K≥ 80116,4 lm/W≤ 25DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 1500-865 SF-ND
0657458		337 mmSuper Flood14200 lm6500 K≥ 80116,4 lm/W≤ 25On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-840 M-DA
0667475		627 mmMedium30000 lm4000 K≥ 80123,0 lm/W≤ 22DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-840 M-ND
0657475		627 mmMedium30000 lm4000 K≥ 80123,0 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-840 S-DA
0667467		627 mmSpot30300 lm4000 K≥ 80124,2 lm/W≤ 22DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-840 S-ND
0657467		627 mmSpot30300 lm4000 K≥ 80124,2 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-840 SF-DA
0667459		627 mmSuper Flood28400 lm4000 K≥ 80116,4 lm/W≤ 25DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-840 SF-ND
0657459		627 mmSuper Flood28400 lm4000 K≥ 80116,4 lm/W≤ 25On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-865 M-DA
0667476		627 mmMedium30000 lm6500 K≥ 80123,0 lm/W≤ 22DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-865 M-ND
0657476		627 mmMedium30000 lm6500 K≥ 80123,0 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-865 S-DA
0667468		627 mmSpot30300 lm6500 K≥ 80124,2 lm/W≤ 22DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-865 S-ND
0657468		627 mmSpot30300 lm6500 K≥ 80124,2 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-865 SF-DA
0667460		627 mmSuper Flood28400 lm6500 K≥ 80116,4 lm/W≤ 25DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 3000-865 SF-ND
0657460		627 mmSuper Flood28400 lm6500 K≥ 80116,4 lm/W≤ 25On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-840 M-DA
0667485		1197 mmMedium60000 lm4000 K≥ 80123,0 lm/W≤ 25DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-840 M-ND
0657485		1197 mmMedium60000 lm4000 K≥ 80123,0 lm/W≤ 25On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-840 S-DA
0667483		1197 mmSpot60600 lm4000 K≥ 80124,2 lm/W≤ 22DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-840 S-ND
0657483		1197 mmSpot60600 lm4000 K≥ 80124,2 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-840 SF-DA
0667481		1197 mmSuper Flood56800 lm4000 K≥ 80116,4 lm/W≤ 25DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-840 SF-ND
0657481		1197 mmSuper Flood56800 lm4000 K≥ 80116,4 lm/W≤ 25On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-865 M-DA
0667486		1197 mmMedium60000 lm6500 K≥ 80123,0 lm/W≤ 25DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-865 M-ND
0657486		1197 mmMedium60000 lm6500 K≥ 80123,0 lm/W≤ 25On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-865 S-DA
0667484		1197 mmSpot60600 lm6500 K≥ 80124,2 lm/W≤ 22DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-865 S-ND
0657484		1197 mmSpot60600 lm6500 K≥ 80124,2 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-865 SF-DA
0667482		1197 mmSuper Flood56800 lm6500 K≥ 80116,4 lm/W≤ 25DALIWhitePDFEulumdatProduct ImageEulumdat
Product ImageHERO 6000-865 SF-ND
0657482		1197 mmSuper Flood56800 lm6500 K≥ 80116,4 lm/W≤ 25On/OffWhitePDFEulumdatProduct ImageEulumdat
