PFLO

IP66
GRP Body
Polycarbonate Diffuser
Stainless Steel Clips
Integral 3hr Emergency Version

Product Selection

Product Filters

		Length (mm)	Lumen Output	Light Colour	CRI (Ra)	Lm/W	UGR Rating	Driver Type	Temp Range
Image	Part Code Article Number	Length (mm)	Lumen Output	Light Colour	CRI (Ra)	Lm/W	UGR Rating	Driver Type	Temp Range	Data	LDT	Polar	BIM
	PFLOA-R1X055/15ND 0921253	660 mm	1890 lm	4000 K	≥ 80	126 lm/W	≤ 25	On/Off	-25 - 25 °C
	PFLOA-R1X115/30ND 0921254	1270 mm	4190 lm	4000 K	≥ 80	131 lm/W	≤ 25	On/Off	-25 - 42 °C
	PFLOA-R1X145/45ND 0921255	1570 mm	5950 lm	4000 K	≥ 80	132 lm/W	≤ 25	On/Off	-25 - 38 °C
	PFLO-1270NDKG840O0850 0921256	1270 mm	8300 lm	4000 K	≥ 80	157 lm/W	> 25	On/Off	-40 - 31 °C
	PFLOA-1270NDKG840O0850 0921257	1270 mm	8550 lm	4000 K	≥ 80	163 lm/W	> 25	On/Off	-40 - 31 °C
	PFLO-0660NDKG840O0250 0921268	660 mm	2400 lm	4000 K	≥ 80	124 lm/W	≤ 25	xFlex	-20 - 33 °C
	PFLOA-0660NDKG840O0250 0921269	660 mm	2440 lm	4000 K	≥ 80	128 lm/W	≤ 25	xFlex	-20 - 25 °C
	PFLO-1270NDKG840O0500 0921270	1270 mm	4870 lm	4000 K	≥ 80	142 lm/W	≤ 25	xFlex	-20 - 36 °C
	PFLOA-1270NDKG840O0500 0921271	1270 mm	5000 lm	4000 K	≥ 80	145 lm/W	≤ 25	xFlex	-20 - 25 °C
	PFLO-1570NDKG840O0650 0921274	1570 mm	6400 lm	4000 K	≥ 80	145 lm/W	≤ 25	xFlex	-20 - 36 °C
	PFLOA-1570NDKG840O0650 0921275	1570 mm	6660 lm	4000 K	≥ 80	151 lm/W	≤ 25	xFlex	-20 - 36 °C
	PFLOA-1570DAKG840O1000 0931247	1570 mm	10500 lm	4000 K	≥ 80	170 lm/W	> 25	DALI-2	-40 - 30 °C
	PFLO-1570DAKG840O1000 0931248	1570 mm	10110 lm	4000 K	≥ 80	163 lm/W	> 25	DALI-2	-40 - 30 °C
	PFLOA-R1X055/15DA 0931253	660 mm	1890 lm	4000 K	≥ 80	126 lm/W	≤ 25	DALI-2	-25 - 25 °C
	PFLOA-R1X115/30DA 0931254	1270 mm	4190 lm	4000 K	≥ 80	131 lm/W	≤ 25	DALI-2	-25 - 42 °C
	PFLOA-R1X145/45DA 0931255	1570 mm	5950 lm	4000 K	≥ 80	132 lm/W	≤ 25	DALI-2	-25 - 36 °C
	PFLO-1270DAKG840O0850 0931256	1270 mm	8300 lm	4000 K	≥ 80	157 lm/W	> 25	DALI-2	-40 - 30 °C
	PFLOA-1270DAKG840O0850 0931257	1270 mm	8550 lm	4000 K	≥ 80	163 lm/W	> 25	DALI-2	-40 - 30 °C
	PFLO-0660DAKG840O0250 0931268	660 mm	2400 lm	4000 K	≥ 80	124 lm/W	≤ 25	DALI-2	-25 - 31 °C
	PFLOA-0660DAKG840O0250 0931269	660 mm	2470 lm	4000 K	≥ 80	128 lm/W	≤ 25	DALI-2	-25 - 31 °C
	PFLO-1270DAKG840O0500 0931270	1270 mm	4870 lm	4000 K	≥ 80	142 lm/W	≤ 25	DALI-2	-20 - 37 °C
	PFLOA-1270DAKG840O0500 0931271	1270 mm	5000 lm	4000 K	≥ 80	145 lm/W	≤ 25	DALI-2	-20 - 37 °C
	PFLO-1570DAKG840O0650 0931274	1570 mm	6410 lm	4000 K	≥ 80	146 lm/W	≤ 25	DALI-2	-25 - 44 °C
	PFLOA-1570DAKG840O0650 0931275	1570 mm	6660 lm	4000 K	≥ 80	151 lm/W	≤ 25	DALI-2	-25 - 44 °C
